50 Micron Stainless Hlau Hlau Mesh Lim Pipe

50 Micron Stainless Hlau Hlau Mesh Lim Pipe

1.Txoj kev ruaj ntseg;

2.Superior zog;

3.Reusability;

4. Yooj yim ua;

5. Yooj yim.

Xa kev nug
Khoom Taw qhia

50 micron stainless hlau xaim mesh lim yeeb nkab yog cov khoom siv tshwj xeeb zoo tagnrho rau kev ua kom huv thiab pom. Nws yog tsim los ntawm kev sib txuas mus tas li ntau cov khaubncaws sab nraud povtseg ntawm woven hlau mesh panels siv cua sov thiab siab los ntawm cov txheej txheem sintering, uas fuses ib tug neeg nyob ntawm tej thiab cov khaubncaws sab nraud povtseg ntawm mesh. Qhov no tsim cov khoom siv nrog cov khoom siv tshwj xeeb, thiab nws tuaj yeem muaj 5, 6, lossis 7 txheej ntawm cov hlau mesh.

50 micron stainless hlau xaim mesh lim yeeb nkab yog qhov muaj ntau yam thiab siv tau rau ntau yam kev siv uas xav tau ntau qhov qhib. Lawv tuaj yeem siv ua ke nrog cov hlau perforated thiab nthuav dav hlau los txhim kho lawv cov peev xwm pom hauv qhov hnyav ib puag ncig. TOPTITECH kev cai tsim stainless hlau lim yog muaj nyob rau hauv ib los yog ntau txheej ntawm woven hlau mesh, thiab peb muaj ntau yam ntawm stainless-steel weaving styles, xws li dawb, twill, tiaj Dutch, thiab rov qab Dutch twill weaves. TOPTITECH hlau mesh lim tuaj yeem raug stamped, sintered, soldered, welded, thiab dov kom loj kom tau raws li koj cov kev xav tau tshwj xeeb.

Zuag qhia tag nrho, 50 micron stainless hlau xaim mesh lim yeeb nkab yog ib qho kev txhim khu kev qha thiab zoo rau txhua tus neeg xav tau kev pom zoo thiab kev ua kom huv. Nws qhov tshwj xeeb ntawm cov khoom siv kho tshuab, ntau yam, thiab cov kev xaiv kho kom haum ua rau nws yog qhov kev xaiv zoo tshaj plaws rau ntau yam kev siv.

Khoom Parameters
Khoom siv

SUS 304 SUS 304L SUS 316 SUS 316L lwm yam alloys muaj raws li xav tau

Txheej

1-5 los yog raws li xav tau

Micron loj

1-200 ua

Cov txheej txheem

Sintering

Phab ntsa Thickness

10-50mm lossis raws li xav tau

Ntev

10-1200 hli

Txoj kab uas hla

10 - 80 hli

Porosity

35 feem pua ​​-60 feem pua
Khoom nta

Ua kom ruaj khov

Vim hais tias ntawm cov txheej txheem sintering 'nce stability, mesh nrog ib tug ntau dua kev faib ua feem ntawm qhib seem los yog xav tau ib tug ruaj ntseg pore loj yog ib tug zoo neeg sib tw.

Superior zog

Sintered hlau daim ntaub lub zog intrinsic tso cai rau high-pressure backwashing thiab zoo kuj rau kua muag thiab punctures.

50 micron stainless steel wire mesh filter pipe 4

Reusability

Diffusion hlau xaim ntaub yuav siv tau ntau zaus yam tsis muaj kev poob qis lossis kev ua haujlwm zoo vim nws yog qhov nyuaj heev thiab yooj yim los ntxuav.

50 micron stainless steel wire mesh filter pipe 5

Yooj yim ua

Sintered hlau ntaub yog heev yooj yim los ua. Rau daim ntawv thov uas yuav tsum tau tswj permeability, nws tuaj yeem ua rau hauv qhov tob lim nruab nrab.

Txawv hom

Raws li tus naj npawb ntawm cov khaubncaws sab nraud povtseg, sintered mesh laminate yuav muab faib ua ob series: ib txheej sintered mesh laminate thiab ntau txheej sintered mesh laminate.



Ib txheej sintered mesh laminate

Txawm hais tias tau ua haujlwm hauv ntau daim ntawv thov, ib txheej woven hlau mesh tsis yog yam tsis muaj qhov tsis zoo. Piv txwv li, vim hais tias qhov pore loj tau raug cuam tshuam, lub mesh muaj ib tug nyiam shred ntawm cov npoo thiab cov xov hlau yuav hloov nyob rau hauv lub weave, hloov tag nrho cov qauv thiab txo cov lim qib.
Cov txheej txheem sintering, uas ua ke nrog cov cua sov thiab siab, tsim cov molecular diffusion-welds ntawm txhua qhov "kev sib tshuam" hauv cov hlau mesh qhov twg cov xov hlau hla dhau thiab qis dua ib leeg txhawm rau txhim kho cov khoom siv thiab lim dej.



Ntau Txheej Sintered Mesh Laminate

Ntau txheej sintered mesh laminate, nrog cov khaubncaws sab nraud povtseg los ntawm ob mus rau ntau tshaj 25, muaj kev txhim kho cov neeg kho tshuab zoo rau cov ntxaij lim dej thiab cov ntawv thov uas muaj qhov hnyav hnyav. Ib txheej hlau mesh tsis yog cov txheej txheem nruj thiab yooj yim puas thaum siv rau lim, sib cais, thiab sifting. Ib qho kev sib sib zog nqus lim tawm tuaj yeem zam qhov kev poob siab los ntawm kev ntxiv rau ib lossis ntau txheej txheej ua ntu zus thiab sintering lawv.
Rau-txheej sintered mesh yog tsim los ntxiv ib txheej ntawm 12-mesh nyob rau sab saum toj ntawm lub hauv paus ruaj khov ntawm tsib-txheej sintered mesh. Rau-txheej sintered mesh laminate yog peb-hauv-ib qho kev kho mob lim phaj uas yuav siv tau rau lim, ntxuav, thiab ziab. Nws tuaj nyob rau hauv ob ntau yam: phua thiab monolithic siv.

50 micron stainless steel wire mesh filter pipe 350 micron stainless steel wire mesh filter pipe 1

Cov khoom siv
  • Aerospace thiab roj / roj kev lag luam
  • Cov kuab tshuaj, xim, dej
  • Filtration, sifting, sizing
  • Qhov cua
  • Pob tawb
  • Cov lim dej
  • Faucet Screens
  • Kab Screens
  • Kho kom zoo nkauj hlau mesh grilles
  • Cov neeg saib xyuas
  • Kho kom zoo nkauj / khoom siv tes ua
Cov khoom ua

Siv cov txheej txheem sintering



50 micron stainless steel wire mesh filter pipe 7

Ntim

50 micron stainless steel wire mesh filter pipe 1
