Hlau hmoov lim cov ntsiab lus yog cov ntsiab lus dav dav, tshwj xeeb muab faib ua titanium hmoov, tooj liab hmoov, stainless hlau hmoov, thiab lwm yam. Thaum cov neeg siv khoom nug txog hmoov-sintered lim cov ntsiab lus, lawv yuav tsum nug cov khoom siv lim uas lawv xav kom tsis txhob muaj kev ntxhov siab; feem ntau hu nrog stainless hlau hmoov lim ntsiab thiab titanium pas nrig lim ntsiab, thiab lwm yam.

Cov kauj ruam tseem ceeb hauv kev tsim cov titanium hmoov sintered lim caij yog raws li hauv qab no: raw titanium hmoov nkag mus rau hauv metallurgical pwm, sintered nyob rau hauv lub tshuab nqus tsev vacuum, yog molded, kho nrog sib tsoo, thiab thaum kawg tau koom ua ke siv lub vuam taub hau. Feem ntau, cov hlau kheej kheej lossis cov hlau tsis sib xws yog siv los tsim cov khoom siv raw rau titanium hmoov-sintered lim ntsiab. Pore loj: 1-200 microns, degree. Cov khoom tiav tuaj nyob rau hauv ntau yam duab, nrog rau cov cones, discs, tiaj daim hlau, thiab cov raj ncaj.

titanium lim tube

sintered titanium hmoov raj

Parameter

Khoom siv: high-purity titanium hmoov

Pom tseeb: 0.22μm-100μm

Length 50mm -1000mm, sab nraud txoj kab uas hla φ8, φ16, φ20, φ{5}}mm

Porosity: 35-40 feem pua

Compressive zog: 0 5-1.5Mpa

Kev ntsuas kub: Tsawg dua lossis sib npaug li 300 degree (ntub xeev)

Ua haujlwm siab sib txawv: 0.6Mpa

Interface daim ntawv: hom tiaj tus, plug-in hom (222 hom, 226 hom), xov, thiab lwm yam., lub interface tuaj yeem hloov kho

Nta

1. Qhov loj thiab porosity yog adjustable;

2. Cov hmoov lim dej muaj lub neej ntev kev pab cuam vim nws cov huab cua permeability siab, zoo heev pom efficiency, homogeneous phab ntsa thickness thiab nruj, ruaj khov permeability coefficient, thiab rov tsim dua tshiab tom qab siv;

3. muaj peev xwm ua tau cua sov thiab hluav taws xob;

4. Thermal shock resistance, low-temperature resistance, thiab high-temperature resistance;

Hmoov-sintered core muaj peb qhov zoo

High mechanical zog

Nws tuaj yeem siv nyob rau hauv cov kev mob siab tsis muaj deforming lossis ua rau cov khoom siv lim dej lossis cov khoom siv hmoov. Lub siab sib txawv ntawm ob sab ntawm lub lim dej tuaj yeem nce ntxiv thaum lub sij hawm pom cov txheej txheem kom nce permeation tus nqi. Nws yog qhov nyuaj rau kev puas tsuaj vim nws lub zog siab thaum ua haujlwm. Txo qhov zaus uas cov khoom lim lim hloov pauv.

Nws muaj zoo thermal conductivity

Vim tias cov khoom siv ntawm cov hmoov hlau yog cov hlau lossis cov hlau uas muaj cov thermal conductivity zoo, cov hmoov raj muaj cov thermal conductivity zoo, thiab muaj kev ua haujlwm zoo thaum tshav kub kub dissipation nyob rau hauv high-temperature applications, txo cov thermal stress ntawm lub lim caij thiab txhim kho lub neej kev pab cuam. ntawm cov lim dej.

Zoo sealing kev ua tau zoo

Cov khoom lim lim tau ua tiav nyob rau hauv ib qho kev xav tau, thiab cov khoom siv lim yuav tsum muaj kev sib khi zoo. Cov khoom siv hmoov hlau yog cov hlau lossis hlau nrog kev ua haujlwm zoo thiab kev sib khi zoo.

Daim ntawv thov teb:

Nws tuaj yeem siv dav hauv kev lag luam tshuaj, kev lag luam kho dej, kev lag luam zaub mov, kev lag luam lom neeg, kev lag luam tshuaj lom neeg, kev lag luam petrochemical, kev lag luam metallurgical, thiab roj purification teb. Cov kev siv ib txwm muaj xws li:

1. Qhov sib txuam sib txuas ntawm cov khoom siv pom hauv kev lag luam tshuaj, ziab peb-hauv-ib lim dej, roj lim thiab impurity tshem tawm, thiab lim cov ntsiab lus rau decarbonization thiab pom kev ruaj ntseg lim, thiab lwm yam.

2. Kev tshem tawm impurity thiab dej pom hauv kev tsim cov khoom siv raw thiab cov tshuaj ua kua hauv kev lag luam chemical, decarbonization filtration, thiab zoo filtration ntawm cov ntaub ntawv.

3. Nyob rau hauv kev lag luam kev kho dej, lub ultrafiltration, RO, thiab EDI system pre-security lim lim thiab tshem tawm impurities, lim tom qab ozone sterilization, thiab ozone aeration.

4. Hauv kev lag luam khoom noj khoom haus, Suav thiab German cov dej haus lim dej, cawv npias, thiab dej ntxhia yog siv los ua kom pom tseeb thiab tshem tawm impurity.

5. Precision filtration ntawm chemical kua khoom, kua raw cov ntaub ntawv, thiab lwm yam nyob rau hauv zoo tshuaj, fais fab nroj tsuag, thiab steel mills, pom, rov qab ntawm ultra-fine hais thiab catalysts, precision pom tom qab resin adsorption, thiab lwm yam.

6. Nyob rau hauv cov nqe lus ntawm cov pa purification, nws tsuas yog muaj xws li cov pom thiab rov qab ntawm chav, ultrafine zoo hais thiab catalysts, purification thiab pom ntawm catalytic gases, thiab precision pom ntawm cov generated resin tom qab adsorption.

Dab tsi yuav tsum tau them sai sai rau thaum tsim cov hlau sintered lim ntsiab?

Thaum xaiv cov khoom lim, koj yuav tsum xav txog qhov nruab nrab lim, lim precision, lim dej txaus, thiab siv ib puag ncig. Kev siv sib txawv xav tau cov lim dej sib txawv, thiab cov ntsiab lus hauv qab no yuav tsum tau xav txog hauv kev tsim:

1) Pore loj: kuj yog hais txog qib micron, qhov pore loj qhia qhov tseeb ntawm qhov nruab nrab koj xav tau lim.

2) Kev poob siab: yog hais txog qhov poob siab tsim thaum cov kua lossis roj ntws los ntawm lub lim. Koj yuav tsum txiav txim siab koj qhov chaw siv thiab muab qhov no rau cov chaw tsim khoom lim.

3) Qhov Kub Kub: Qhov kub npaum li cas ntawm cov lim lim yuav nyob hauv nws qhov chaw ua haujlwm, cov hlau alloy koj xaiv rau lub lim dej yuav tsum muaj peev xwm tiv taus qhov kub ntawm qhov chaw ua haujlwm.

4) Lub zog: Sintered lim cov ntsiab lus yog qhov zoo tshaj plaws rau kev xav tau lub zog siab, lwm qhov zoo dua yog tias lawv muaj lub zog tib yam rau pem hauv ntej lossis rov qab ntws.

Cov ntaub ntawv dab tsi yuav tsum tau muab rau cov chaw tsim khoom kom tso qhov kev txiav txim?

1) Lub hom phiaj: suav nrog kev siv ib puag ncig, pom tseeb, thiab lwm yam.

2) Lim xov xwm

3) Dab tsi yuav tsum tau them sai sai rau corrosion, xws li acid thiab alkali tsis kam

4) Txawm hais tias muaj kev ua haujlwm tshwj xeeb, xws li kub, siab

5) Cov pa phem dab tsi yuav raug ntsib

6) Loj, zoo, siab

7) Qhov xav tau

8) Yuav ua li cas rau nruab
